Charging Cables
Type 2 to Type 2 charging cables for socket wallboxes and public AC chargers — single- or three-phase, 16 A or 32 A, in 5 m or custom lengths.
- Single or three-phase
- 16 / 32 ASingle or three-phase
- Custom lengths
- 5 mCustom lengths
- Mating cycles
- > 10,000Mating cycles
- Connected
- IP54Connected
Models
- MZ-CBL16-1
- MZ-CBL32-1
- MZ-CBL16-3
- MZ-CBL32-3
Certified to CE and CB, tested by TÜV and SGS; certificate copies for the exact model on request.
Overview
MOLZEX charging cables connect socket wallboxes and public AC chargers to any car with a Type 2 inlet. They come in 16 A and 32 A, single- and three-phase, with 5 m as standard and other lengths on request.
Highlights
- Flexible TPU cable that stays soft in the cold
- Flame-retardant UL94 V-0 connector housing
- Dust caps on both ends
- Carry bag available
Best for: Drivers, dealers and fleets using socket chargers
Specifications
Models
Type 2 plug to Type 2 connector
| Model | MZ-CBL16-1 | MZ-CBL32-1 | MZ-CBL16-3 | MZ-CBL32-3 |
|---|---|---|---|---|
| Rated current | 16 A | 32 A | 16 A | 32 A |
| Phases | 1-phase | 1-phase | 3-phase | 3-phase |
| Max. power | 3.7 kW | 7.4 kW | 11 kW | 22 kW |
Common specifications
- Standard
- IEC 62196-2
- Voltage
- 1P 220–250 V / 3P 380–415 V
- Length
- 5 m standard; custom on request
- Ingress protection
- IP54 (connected)
- Housing
- UL94 V-0 flame retardant
- Contact resistance
- < 0.5 mΩ
- Insulation resistance
- > 1000 MΩ
- Withstand voltage
- 2000 V
- Operating temperature
- −30 °C to +50 °C
Figures may change with product updates — the datasheet sent with your quotation is binding.
Engineering
- 01
Durable
More than 10,000 plug-in cycles.
- 02
Safe
Flame-retardant housing and silver-plated contacts.
- 03
Your length
5 m standard, other lengths for OEM orders.
Options
- Custom length
- Carry bag
- Private-label packaging
Where it works best
FAQ
Which cable do I need?
Match the car’s onboard charger: a 32 A three-phase cable works for every Type 2 car and is the most future-proof choice.
Get a quote for the Charging Cables
Tell us the market, power level and quantity. An engineer replies with a model list and price.
