PCE Series
A three-phase portable charger with a red CEE industrial plug and a Type 2 socket — full 11 or 22 kW charging wherever there is an industrial outlet.
- 3-phase
- 11–22 kW3-phase
- Red industrial plug
- CEERed industrial plug
- Adjustable
- 6–32 AAdjustable
- Rain and dust protected
- IP65Rain and dust protected
Models
- MZ-PCE11
- MZ-PCE22
Certified to CE and CB, tested by TÜV and SGS; certificate copies for the exact model on request.
Overview
The PCE Series is a portable charger with full wallbox power. A red CEE plug connects to any three-phase industrial outlet, and the Type 2 socket on the front accepts any Type 2 cable.
It suits workshops, dealerships, construction sites and events, where outlets already exist but a fixed charger is not worth installing.
Highlights
- Full wallbox power without a fixed installation
- Red CEE 16 A or 32 A plug
- Type 2 socket outlet — use any Type 2 cable
- Wall bracket for semi-fixed use
Best for: Workshops, construction sites, events, dealerships and rental properties
Specifications
IEC versions
Current adjustable · RFID optional
| Model | MZ-PCE11 | MZ-PCE22 |
|---|---|---|
| Max. power | 11 kW | 22 kW |
| Plug | CEE 16 A red (5-pin) | CEE 32 A red (5-pin) |
| Current range | 6–16 A | 6–32 A |
Common specifications
- Charging mode
- Mode 2
- Input
- 3P+N+PE 380–415 V via CEE plug
- Output
- Type 2 socket
- Fault protection
- 30 mA Type A + 6 mA DC
- Start
- Plug & charge or RFID
- Ingress protection
- IP65
- Operating temperature
- −25 °C to +55 °C
Figures may change with product updates — the datasheet sent with your quotation is binding.
Engineering
- 01
22 kW anywhere
Workshops and event sites already have CEE outlets — no new installation needed.
- 02
Portable or semi-fixed
Carry it, or hang it on its wall bracket next to the outlet.
- 03
Any cable
The Type 2 socket works with the driver’s own cable.
Installation
- Plug into a CEE outlet protected by an RCD-rated breaker
Options
- RFID reader
- Wall bracket
- Carry case
Where it works best
FAQ
Which outlet does it need?
A red five-pin CEE outlet: 16 A for the 11 kW model, 32 A for the 22 kW model.
Is a cable included?
The unit has a Type 2 socket; Type 2 cables are available separately.
Get a quote for the PCE Series
Tell us the market, power level and quantity. An engineer replies with a model list and price.
